OEM AC DC 400w 600w 800w Carbon Brush Dry Vacuum Cleaner Motor

Our products are central parts of household, industrial vacuum cleaners,
spray guns, hair dryers, garden tools.
  • AC DC 400w 600w 800w Carbon Brush Dry Vacuum Cleaner Motor
  • AC DC 400w 600w 800w Carbon Brush Dry Vacuum Cleaner Motor
  • AC DC 400w 600w 800w Carbon Brush Dry Vacuum Cleaner Motor
  • AC DC 400w 600w 800w Carbon Brush Dry Vacuum Cleaner Motor
  • AC DC 400w 600w 800w Carbon Brush Dry Vacuum Cleaner Motor
  • AC DC 400w 600w 800w Carbon Brush Dry Vacuum Cleaner Motor
Dry vacuum cleaner motor

AC DC 400w 600w 800w Carbon Brush Dry Vacuum Cleaner Motor

  • Bigger size fan motor
  • Full copper wire  pure copper carbon brush holder
  • Stable performance, Low current and large torque

Product feature

  1. YH-(D-1/2),voltage100-240V, rated input power 300-600W, rated frequency 50/60Hz, max vacuum degree 18.8kpa, max air flow 2.22 M3/min, temperature rise 70K, Noise less than 95dB, Spark less than 1, Class of insulation A,B,C.D, E, max efficiency 34%.
  2. This product can also be made 12V , 24V , 36V ,48V.
  3. Wide range of uses,Vacuum cleaner motor, small portable motor accessories, home mini sprayer.
  4. The motor has Long life which can last above 500hours.

Product Specification

Patameters/Models

YH-(D-1/2)

Tolerance Value

Product diameter(mm)

106

/

Product Height (mm )

98.2

/

Rated voltage(V)

100-240

/

Rated frequency(Hz)

50/60

/

Rated input power(W)

300-600

+10% -10%

Max vacuum degree(KPa)

13.9-18.8

-5%

Max air flow(M3/min)

1.69-2.22

-8%

Temperature rise(K)

≤70

/

Noise(dB)

≤95

/

Spark

<Level 1

/

Class of insulation

E

/

Max efficiency

34%

-10%

Product drawing

About us

Zhoushan YeHao Electrical Appliance Co., Ltd is located in the beautiful Zhoushan Islands. Its predecessor, Suzhou PowerX Motors Co., Ltd., was established in 2002, specializing in various vacuum motors for 20 years The products are sold all over the world. With the continuous development of the market and the rapid growth of business volume, with an area of 15,680 square meters and an annual output of 12 million units, Sales amount 600 million.

YeHao as professional China AC DC 400w 600w 800w Carbon Brush Dry Vacuum Cleaner Motor and AC DC 400w 600w 800w Carbon Brush Dry Vacuum Cleaner Motor factory, we offer custom AC DC 400w 600w 800w Carbon Brush Dry Vacuum Cleaner Motor for sale at wholesale price. Our company has set its strategic objective which is “ high quality , High precious ,Best Service ”.We improve products with technology and take innovation as the goal of development in order to design, manufacture and produce various types of motors for the market. The company passed ISO9001 and products also got CCC, CE, ROHS, REACH and other related certifications.
